Gigabit Wi-Fi Speeds with MU-MIMO Technology
EAP225-Outdoor supports simultaneous dual band speed of up to 1200Mbps. Outfitted with the latest 802.11ac Wave 2 MU-MIMO
technology, EAP225-Outdoor can communicate with multiple clients at the same time which making it ideal for high density environment.
Excellent Hardware Designs
With special design of its antenna, appearance, power options and installation methods, EAP225-Outdoor can perfectly fit for different
scenarios both indoors and outdoors.
Detachable Antennas
EAP225-Outdoor is designed with 2 Omni-directional detachable antennas, which means other antennas can also be attached for your specific
demands.
Delicate Appearance Even Better for Indoor Applications
EAP225-Outdoor is just similar to a cellphone, with dimension: 215 x 46 x 27mm.
Multiple PoE Options for Easy Installation
EAP225-Outdoor supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE
adapter.
Flexible Deployment
EAP225-Outdoor can be easily installed on a wall or to a pole with the mounting kits provided.
Wi-Fi That Goes the Distance
With high transmission power and high gain omnidirectional antennas, EAP225-Outdoor provides stable wireless coverage at a range up to
200m+* at 2.4GHz and 300m+* at 5GHz in outdoor settings.
*Based on field tests. Real transmission range may vary, according to environment, receiving device, etc.
Specially Designed Weatherproof Enclosure for Outdoor Environment
Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against harsh outdoor condition.
Efficient Centralized Network Management
With Omada Controller software, small and medium-sized businesses can take command of hundreds of indoor and outdoor access points all
from a single location. It’s network management as it should be - efficient and intuitive.
| SPECIFICATIONS |
| Main Design |
| LAN Interfaces |
Gigabit Ethernet(RJ-45) Port*1 |
| Wireless Frequency |
2.4GHz/5GHz |
| Wi-Fi Standards |
IEEE 802.11a/b/g/n/ac |
| Maximum Data Rate |
Up to 300Mbps(2.4GHz)+867Mbps(5GHz) |
| Antennas |
2 Dual-Band Omni Antennas (2.4G: 3dBi, 5G: 4dBi) |
| Centralized Management |
| Omada Controller Software |
• |
| Security |
| Captive Portal Authentication |
• |
| Access Control |
• |
| Wireless MAC Adress Filtering |
• |
| Wireless Isolation between Clients |
• |
| SSID to VLAN Mapping |
• |
| Rogue AP Detection |
• |
| WEP Encryption |
64/128/152-bit |
| |
|
| WPA/WPA2-Personal Encryption |
• |
| WPA/WPA2-Enterprise Encryption |
• |
| 802.1X Support |
• |
| Wireless Function |
| Multiple SSIDs |
16(8 for each band) |
| Enable/Disable Wireless Radio |
• |
| Automatic Channel Assignment |
• |
| Transmit Power Control |
Adjust transmit Power on dBm |
| QoS(WMM) |
• |
| MU-MIMO |
• |
| Airtime Fairness |
• |
| Beamforming |
• |
| Band Steering |
• |
| Rate Limit |
• |
| Load Balance |
• |
| Reboot Schedule |
• |
| Wireless Schedule |
• |
| Wireless Statistics |
Based on SSID/AP/Client |
| Support Data Rates |
| 802.11n |
6.5 Mbps to 300Mbps (MCS0-MCS15,VHT20/40) |
| 802.11g |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b |
1, 5.5, 11 Mbps |
| 802.11a |
6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11ac |
5G: 6.5 Mbps to 867Mbps
(MCS0-MCS9, NSS=1 to 2 VHT20/40/80)
2.4G: 78 Mbps to 300Mbps
(MCS8-MCS9, NSS=1 to 3 VHT20/40) |
| Physical & Environment |
| Power Supply |
802.3af/A PoE or 24V Passive PoE
(+4,5pins; -7,8pins. PoE Adapter Included) |
| Maximum Power Consumption |
10.5W |
| Mounting |
Pole/Wall/Fast Mounting (Kits included) |
| Certifications |
CE, FCC, RoHS |
| Dimensions (WxDxH) |
214.9 x 46 x 26.7mm |
| Environment |
Operating Temperature: -30°C~70°C (-22°F~158°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
| Package Contents |
Access Point EAP225-Outdoor
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide
Waterproof Ruber Insert
Waterproof Antenna |
